Structural Health Coherence · v1.0

THP—Structure

Harmonic Coherence for Civil & Industrial Structures

One number. The complete health of any structure — from a cable-stayed bridge to an offshore wind turbine. THP-Structure monitors vibration, structural integrity, and load coherence in real time, flagging drift before it becomes failure.

↓ Download on App Store Explore Features
φ Golden Ratio Core
6 Structure Profiles
3 Coherence Axes
iOS + macOS Universal App
Overview
THP-Structure — Structural Health Coherence
Structural coherence — measured in real time.
⬡
THP-Structure is built on the H-Space³ framework — a theoretical discovery establishing that structural health can be quantified through harmonic coherence, indexed by the golden ratio φ = 1.6180339887.
Refs: Chopra (2017) · Farrar & Worden (2012) · Frangopol (2011) · ISO 6897 · IEC 61400-3
H-Space³ · 2025
Structure Profiles

Six structural archetypes

01 · BRIDGE
Cable-Stayed Bridge
Symmetric strain monitoring across main spans. Damping ratio tracking, wind-induced vibration, traffic load coherence, and fatigue accumulation via Miner's Rule.
Strain symmetry Miner's Rule Wind load
02 · SKYSCRAPER
Skyscraper
Wind-induced sway coherence, thermal deformation tracking, floor load distribution, and dynamic amplification factor monitoring across full height.
Wind sway Thermal drift Load floors
03 · OFFSHORE
Offshore Platform
Wave loading coherence, marine corrosion fatigue, combined wind-wave excitation, and structural asymmetry monitoring for oil & gas infrastructure.
Wave height Marine fatigue O&G
04 · WIND TURBINE
Wind Turbine (Onshore)
Rotor-induced vibration, tower foundation monitoring, nacelle acceleration envelope, and blade asymmetry detection for onshore wind energy assets.
Rotor vibration Foundation Blade asym.
05 · OFFSHORE WIND ↑
Offshore Wind Turbine
Monopile foundation. Campbell Diagram margin monitoring (1P/3P resonance window). Hydrodynamic damping. North Sea wave loading. IEC 61400-3 compliance reference.
Campbell Diagram 1P/3P margin Monopile IEC 61400-3
06 · INDUSTRIAL
Industrial Plant
Process-induced vibration, structural load under operational cycles, thermal cycling coherence, and equipment-induced resonance for manufacturing and processing facilities.
Process vibration Thermal cycling Load cycles
Critical Application

Offshore Wind —
Campbell Diagram monitoring

The margin between
1P and 3P is everything.

Every offshore wind turbine operates in a frequency window — the tower's natural frequency must sit between the rotor rotation frequency (1P) and three times that frequency (3P). This is the Campbell Diagram constraint. Violate it and the structure resonates. With resonance comes fatigue. With fatigue comes collapse.

As a tower ages, its natural frequency falls — steel corrodes, welds fatigue, grout in the monopile connection loosens. The gap between the natural frequency and the 1P lower bound narrows. When it closes, the tower is in resonance with its own rotor.

THP-Structure monitors this margin continuously. The resonanceCoherence axis within Vibration Coherence tracks the gap in real time. When the margin begins to shrink — weeks or months before any displacement measurement detects anything — THP starts falling and insights fire.

0.28 Hz
Natural freq reference (monopile)
0.06 Hz
1P/3P margin — tight, critical
300k+
Onshore turbines operating globally
IEC 61400-3
Reference standard — offshore design
THP Classification

Five structural regimes

THP ≥ 0.90
Full Coherence
Structure operating at or near commissioning state. All axes within design envelope.
0.75 – 0.89
Stable Operation
Normal aging trajectory. Coherence preserved. No immediate intervention required.
0.60 – 0.74
Coherence Drift
Early degradation signal. Monitor closely. Schedule inspection window.
0.45 – 0.59
Maintenance Alert
Structural coherence compromised. Maintenance required before further loading.
THP < 0.45
Critical State
Harmonic collapse. Immediate structural review. Cease loading until assessed.
Core Modules

Everything in one app

01 · LIVE MONITOR
Real-Time THP Dashboard
Three coherence gauges — Vibration, Structural, Load — update continuously from the UDP stream. Animated collapse chart tracks the last 500 readings. Structural insights fire automatically when any axis drifts.
02 · GRACE STATE
Commissioning State Memory
THP-Structure learns the structure's commissioning THP and tracks every future reading against it. Coherence Loss is not an abstract threshold — it's measured against what this specific structure has already demonstrated it can achieve.
03 · REMAINING LIFE
Service Life Projection
Linear regression on the THP trajectory projects time to maintenance threshold (THP = 0.60). Confidence adjusts with reading count — low with 10 readings, high with 1095. The more you monitor, the more precise the forecast.
04 · IMPORT DATA
Smart Paste & CSV Analysis
Paste or drop any CSV/JSON sensor dataset. Automatic column detection by field name — works with any sensor brand or format. Analyse 3 years of historical data in seconds. Drop the bridge_3years.csv and see the trajectory immediately.
05 · EXPORT
Results to Clipboard
Export analysis results as CSV to clipboard with one tap — THP, vibration, structural, load coherence, regime, fatigue %, remaining life, limiting axis, and timestamp. Paste directly into Excel, Numbers, or Python.
06 · HISTORY
Session Reading Log
Every reading from the current session is logged with THP, regime, limiting axis, and fatigue. Export full session history as CSV. Compare sessions across inspection visits. Track fatigue accumulation over operational years.
Target Audience

Who uses THP-Structure

Infrastructure Engineering
Bridges, Tunnels & Civil Structures
  • Structural health engineers monitoring bridge fatigue
  • Infrastructure asset managers tracking service life
  • Construction phase monitoring contractors
  • Civil engineering research institutions
  • Transport authority inspection teams
Wind Energy
Onshore & Offshore Wind O&M
  • O&M operators monitoring turbine tower health
  • Offshore wind developers (North Sea, Taiwan, Brazil)
  • Turbine OEM inspection and service teams
  • SCADA system integrators adding coherence layer
  • Structural consultancies for wind farm due diligence
Offshore Oil & Gas
Platforms & Subsea Structures
  • Platform integrity engineers — fatigue monitoring
  • Inspection, maintenance and repair (IMR) contractors
  • Asset integrity management teams
  • Mooring and riser structural monitoring
Academia & Research
Universities & Research Institutions
  • Civil and structural engineering research groups
  • SHM methodology validation and benchmarking
  • Graduate courses in structural dynamics
  • Research into φ-based coherence frameworks
Data Format

Connect any sensor system

THP-Structure receives data via UDP port 55160 or by importing CSV/JSON files. Column detection is automatic — the parser recognises field names regardless of sensor brand or format.

Field Type Unit Description
freqREQUIREDHzDominant structural frequency
dampREQUIREDζ (0–1)Damping ratio
slREQUIREDµεStrain — left / port side
srREQUIREDµεStrain — right / starboard side
defREQUIREDmmDeformation / displacement
fatREQUIRED0–1Fatigue index (cumulative Miner's Rule)
loadREQUIREDkN or kPaApplied load
tempREQUIRED°CAmbient temperature
toptionalsTimestamp (Unix or relative seconds)
ax / ay / azoptionalm/s²Triaxial acceleration
excfoptionalHzExcitation frequency (rotor, traffic, wave)
windoptionalm/sWind speed
waveoptionalmWave height (offshore profiles)
sidoptionaltextSensor ID or location tag
// Minimal CSV example — bridge daily reading t,freq,damp,sl,sr,def,fat,load,temp 0,0.200,0.015,810,805,142,0.04,36,18 86400,0.199,0.016,812,808,143,0.041,38,19 // Offshore wind with wave and excitation frequency t,freq,damp,sl,sr,def,fat,load,temp,wind,wave,excf 0,0.281,0.014,1090,1085,398,0.06,7800,8,14.2,3.1,0.21
Support & Technical

THP-Structure platform

Contact
Get in touch
Technical questions, sensor integration help, or bug reports.

web@musicamania.com.br

Response within 24 hours on business days.
Requirements
System
→ iOS 17.0 or later
→ macOS 14.0 Sonoma or later
→ iPhone · iPad · Mac (Apple Silicon or Intel)
UDP: Wi-Fi, same subnet
Port: 55160 (configurable)
Formats: CSV · JSON · TXT · DAT
Privacy
No data collected
THP-Structure is fully offline. No account required, no analytics, no cloud services. All session data is stored locally on your device.

Full Privacy Policy →

© 2026 Musicamania Tecnologia · $49.99 · Universal iOS + macOS
